The FusionServer 2288H V6 is a 2U 2-socket rack server designed with flexible configurations, making it an ideal choice for cloud computing, virtualization, database management, and big data workloads. It can be configured with two Intel® Xeon® Scalable processors, up to 32 DDR4 RAM slots, and 14 PCIe expansion slots, supporting extensive local storage resources.
This server integrates patented technologies such as DEMT (Dynamic Energy Management Technology), intelligent power consumption management, and FDM (Fault Diagnosis & Management). With optional FusionDirector full lifecycle management software, it effectively reduces operational costs and improves return on investment.
| Server Model | FusionServer 2288H V6 |
| Form Factor | 2U rack server |
| Processors | One or two 3rd Gen Intel® Xeon® Scalable Ice Lake processors (8300/6300/5300/4300 series), TDP up to 270 W |
| Local Storage |
• 8-31 x 2.5-inch SAS/SATA/SSD drives • 12-20 x 3.5-inch SAS/SATA drives • 4/8/16/24 NVMe SSDs • Supports Dual M.2 SSDs |
| RAID Support | RAID 0, 1, 10, 1E, 5, 50, 6, or 60; optional supercapacitor for cache data protection; remote web-based configuration. |
| Network | OCP 3.0 NICs supported via two FlexIO card slots; Hot swappable function supported. |
| PCIe Expansion | Maximum of 14 PCIe 4.0 slots (including dedicated RAID and OCP 3.0 slots). |
| Management | iBMC chip with dedicated GE port; Supports Redfish, SNMP, IPMI 2.0, HTML5/VNC KVM; Optional FusionDirector software. |
| Operating Systems | Windows Server, SUSE Linux, VMware ESXi, Red Hat, CentOS, Oracle, Ubuntu, Debian, etc. |
| Security | Power-on/Admin passwords, TPM 2.0, security panel, secure boot, and cover opening detection. |
| Dimensions | 86.1 mm x 447 mm x 790 mm (3.39 in. x 17.60 in. x 31.10 in.) |
| Power Supply | Hot-swappable PSUs in 1+1 redundancy (Options: 900W, 1500W, 2000W, 3000W Platinum/Titanium; AC/DC/HVDC). |
As a leading integrated IT solutions provider, we combine cutting-edge manufacturing, dedicated R&D facilities, and a robust global distribution network to deliver comprehensive infrastructure services. With a team of over 300 highly skilled professionals, including more than 150 certified engineers, we bring 15 years of proven expertise in designing, deploying, and maintaining mission-critical IT environments.
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided. We utilize reinforced shipping materials to protect sensitive electronic components during transit.
