New xFusion Fusionserver 2288H V6 Computer Server 25x2.5 Inch Drive Xeon 4310*1 2288H V6 2U 2-socket Rack Server

Product Description

⚡ FusionServer 2288H V6 Overview
FusionServer 2288H V6 is a 2U 2-socket rack server with flexible configurations, which can be widely used for cloud computing, virtualization, database, and big data workloads. It can be configured with 2-socket Intel® Xeon® Scalable processors, 32 DDR4 RAM, 14 PCIe expansion slots, and supports large local storage resources. It integrates patented technologies such as DEMT, intelligent power consumption management, FDM intelligent fault management, and optional FusionDirector full lifecycle management software, which can effectively reduce operations cost and improve return on investment.
📸 Product Display
FusionServer 2288H V6
FusionServer 2288H V6 Front View
FusionServer 2288H V6 Internal View
📋 Technical Specifications
Server Model FusionServer 2288H V6
Form Factor 2U rack server
Processors One or two 3rd Gen Intel® Xeon® Scalable Ice Lake processors (8300/6300/5300/4300 series), TDP up to 270 W
Local Storage Supports various drive configurations and hot swappable:
• 8-31 x 2.5-inch SAS/SATA/SSD drives
• 12-20 x 3.5-inch SAS/SATA drives
• 4/8/16/24 NVMe SSDs
• 45 x 2.5-inch drives or 34 full-NVMe SSDs
Flash storage: Dual M.2 SSDs
RAID support Supports RAID 0, 1, 10, 1E, 5, 50, 6, or 60, optional supercapacitor for cache data power failure protection, RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration.
Network Provides expansion capability of multiple types of networks. Provides OCP 3.0 NICs. The two FlexIO card slots support two OCP 3.0 network adapter respectively. Hot swappable function supported.
PCIe Expansion Provides a maximum of fourteen PCIe 4.0 slots, including one PCIe slot dedicated for RAID card, two FlexIO card slots dedicated for OCP 3.0, and eleven PCIe 4.0 slots for standard PCIe cards.
Chip Set Intel C621A
Management The iBMC chip integrates one dedicated GE management port for fault diagnosis, automated O&M, and hardware security. Supports Redfish, SNMP, and IPMI 2.0. Optional FusionDirector management software for advanced lifecycle management.
Operating Systems Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle, Ubuntu, Debian, etc.
Security Features Power-on password, administrator password, TPM 2.0, security panel, secure boot, and cover opening detection.
Operating Temp 5°C to 45°C (41°F to 113°F) (ASHRAE Classes A1 to A4 compliant)
Certifications CE, UL, CCC, FCC, VCCI, RoHS, etc
Dimensions 86.1 mm x 447 mm x 790 mm (3.39 in. x 17.60 in. x 31.10in.)
Power Supply Two hot-swappable PSUs in 1+1 redundancy mode. Options: 900W/1500W/2000W/3000W AC Platinum/Titanium, 1500W HVDC, 1200W DC.
🏗️ Infrastructure Expertise
Production Facility
As a leading integrated IT solutions provider, we combine cutting-edge in-house manufacturing, dedicated R&D facilities, and a robust global distribution network to deliver comprehensive end-to-end infrastructure services. With a team of over 300 highly skilled professionals, including more than 150 certified engineers, we bring 15 years of proven expertise in designing, deploying, and maintaining mission-critical IT environments for enterprises worldwide. Our vertically integrated approach ensures seamless quality control from component sourcing to final implementation.
Authorized Provider for:
Computing servers
Network storage
Network switches
CPU, RAM, Hard Drives, and accessories
📦 Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Exhibition Display
Secure Packing
Shipping Logistics
❓ Frequently Asked Questions
Q1: When can I get the quotation? A1: We usually quote within 24 hours after receiving your inquiry. If you are in a hurry, please inform us by email or telephone. We will give priority to your inquiry.
Q2: Why should we choose your server solutions? A2: We offer the best quality and reputation. Our whole machine products provide a 3-year replacement warranty. We have a complete supply chain to deal with after-sales problems and all components are original brand chips, strictly tested before delivery.
Q3: What is the minimum order quantity (MOQ)? A3: Different products have different MOQs. Please let us know your requirements and we will try our best to meet your needs. Small orders are also welcome.
Q4: How do you handle payment security? A4: We accept various secure payment methods including credit cards, bank card transfers, T/T, and other standard financial platforms to eliminate your concerns.
Q5: Is the FusionServer 2288H V6 suitable for virtualization? A5: Yes, the 2288H V6 is specifically designed for high-performance workloads including cloud computing, virtualization, big data, and large-scale databases.
Q6: What certifications do your products hold? A6: Our servers meet global standards and hold certifications such as CE, UL, CCC, FCC, VCCI, and RoHS, ensuring safety and quality compliance.
